Description
Airman Compressor – engineered with precision Japanese Technology to deliver reliable, efficient, and low-maintenance compressed air solutions for a wide range of industrial applications. Please send your inquiry to us, our team will recommend you the suitable model.
Category: Air Compressors, Airman, SP
| MODEL PDS-185S-6C2 | |
|---|---|
| COMPRESSOR | |
| Type | Rotary Twin Screw, Single-Stage, Oil-cooled |
| Free Air Delivery (m³/min) | 5.2 |
| Rated Operating Pressure MPa (kgf/cm²) [psi] | 0.69 (7.0) [100] |
| Compressor Oil Capacity (L) | 15 |
| Air Outlet Valve | 3/4" ×2 |
| ENGINE | |
| Make / Model | YANMAR 4TNV88-BXDHKS1 |
| Type | Direct-Injection |
| Rated Output PS (kW) / rpm | 47.5 (34.9) / 3000 |
| Engine Oil Capacity (L) | 7.4 |
| Fuel Tank Capacity (L) | 90 |
| Battery | 80D26RX1 |
| DIMENSION & WEIGHT | |
| Overall Length mm (inch) | 2960 (116.5) |
| Overall Width mm (inch) | 1650 (65.0) |
| Overall Height mm (inch) | 1510 (59.4) |
| Dry (Operating) Weight (kg) | 860 (960) |
| Tire Size | 175/80R13 97/95N ×2W |
| OTHER | |
| Sound Power Level dB | 98 |
| Sound Power Level dB(A) | 71 |
| Emissions Regulation | US Tier 3 |
