Description
A 5-horsepower high-pressure unit. It uses a larger flywheel and finned copper cooling tubes to manage the heat generated by higher compression ratios.
Category: Fusheng, HP
| MODEL HTA-80 | |
|---|---|
| SPECIFICATIONS | |
| Phase | 1PH |
| Motor HP | 5 |
| Motor Kw | 3.7 |
| Cylinder Bore (mm) | 80 |
| No. of Cylinders | 2 |
| Cylinder Stroke (mm) | 60 |
| Comp. RPM | 954 |
| Piston Displacement (L/min) | 575 |
| Working Pressure (kg/cm²) | 12 |
| Air Receiver Capacity Liter (L) | 155 |
| Air Receiver Max Pressure (kg/cm²) | 13.5 |
